RYZEN 9 9900X3D BOX

Una potente CPU per desktop, con tecnologia AMD 3D V-Cache™ di seconda generazione, che consente di ottenere prestazioni estreme per i giochi, la creazione, lo streaming o qualsiasi altro carico di lavoro.

https://www.amd.com/en/products/processors/desktops/ryzen/9000-series/amd-ryzen-9-9900x3d.html

• General Specifications

  Name

  AMD Ryzen™ 9 9900X3D

  Family

  Ryzen

  Series

  Ryzen 9000 Series

  Form Factor

  Desktops , Boxed Processor

  Market Segment

  Enthusiast Desktop

  AMD PRO Technologies

  No

  Regional Availability

  Global

  Former Codename

  Granite Ridge AM5

  Architecture

  Zen 5

  # of CPU Cores

  12

  Multithreading (SMT)

  Yes

  # of Threads

  24

  Max. Boost Clock

  Up to 5.5 GHz

  Base Clock

  4.4 GHz

  L1 Cache

  960 KB

  L2 Cache

  12 MB

  L3 Cache

  128 MB

  Default TDP

  120W

  Processor Technology for CPU Cores

  TSMC 4nm FinFET

  Processor Technology for I/O Die

  TSMC 6nm FinFET

  Package Die Count

  3

  Unlocked for Overclocking

  Yes

  AMD EXPO™ Memory Overclocking Technology

  Yes

  Precision Boost Overdrive

  Yes

  Curve Optimizer Voltage Offsets

  Yes

  AMD Ryzen™ Master Support

  Yes

  CPU Socket

  AM5

  Supporting Chipsets

  A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850

  CPU Boost Technology

  Precision Boost 2

  Instruction Set

  x86-64

  Supported Extensions

  AES , AMD-V , AVX512 , AVX2 , AVX , FMA3 , MMX-plus , SHA , SSE2 , SSE4.2 , SSE4A , SSE4.1 , SSE3 , SSSE3 , SSE , x86-64

  Thermal Solution (PIB)

  Not Included

  Recommended Cooler

  Liquid cooler recommended for optimal performance

  Max. Operating Temperature (Tjmax)

  95°C

  Launch Date

  03/12/2025

  *OS Support

  Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit

  Connectivity

  Native USB 4 (40Gbps)

  4

  Native USB 3.2 Gen 1 (5Gbps)

  1

  PCI Express® Version

  PCIe® 5.0

  Native PCIe® Lanes (Total/Usable)

  28 , 24

  NVMe Support

  Boot , RAID0 , RAID1 , RAID5 , RAID10

  System Memory Type

  DDR5

  Memory Channels

  2

  Max. Memory

  192 GB

  System Memory Subtype

  UDIMM

  Max Memory Speed

  2x1R

  DDR5-5600

  2x2R

  DDR5-5600

  4x1R

  DDR5-3600

  4x2R

  DDR5-3600

  ECC Support

  Yes (Requires mobo support)

  Graphics Capabilities

  Graphics Model

  AMD Radeon™ Graphics

  Graphics Core Count

  2

  Graphics Frequency

  2200 MHz

  USB Type-C® DisplayPort™ Alternate Mode

  Yes

  Product IDs

  Product ID Boxed

  100-100001368WOF

  Product ID Tray

  100-000001368

  Key Features

  Supported Technologies

  AMD EXPO™ Technology , AMD Ryzen™ Technologies
